Compact Poclain MS50 Hydraulic Pump Motor Parts , Hydraulic Pump Repair Kit

I'm Online Chat Now

Compact Poclain MS50 Hydraulic Pump Motor Parts , Hydraulic Pump Repair Kit

China Compact Poclain MS50 Hydraulic Pump Motor Parts , Hydraulic Pump Repair Kit supplier
Compact Poclain MS50 Hydraulic Pump Motor Parts , Hydraulic Pump Repair Kit supplier Compact Poclain MS50 Hydraulic Pump Motor Parts , Hydraulic Pump Repair Kit supplier Compact Poclain MS50 Hydraulic Pump Motor Parts , Hydraulic Pump Repair Kit supplier

Large Image :  Compact Poclain MS50 Hydraulic Pump Motor Parts , Hydraulic Pump Repair Kit

Product Details:

Place of Origin: CHINA
Brand Name: HL
Certification: ISO9001
Model Number: MS25

Payment & Shipping Terms:

Minimum Order Quantity: 1Set
Packaging Details: Paper and wooden Packing
Contact Now
Detailed Product Description
Performance: Large Torque With Low Speed Displacement: 160cc,225cc,255cc,280cc,325cc,
Max. Torque: 1620 N.m Brake: With Brake & Without Brake
Application: GANTRY CRANE EQUIPMENT Brand Name: Poclian MS50

Poclain MS50 Hydraulic Motor Spare Parts:



1) These are the spare parts for Poclain MS50, Hydraulic Motor Spare Parts, and alll of them could be best replacement of the original Poclain MS50 hydraulic motors.



2) Include drive shaft, front cover, stator, rotor, plunger piston, roller, distributor, rear cover, dynamic friction, static friction, checking cylinder, break plunger, cover plate break shaft, brake shaft etc.




This Series Hydraulic Motor is one kind of low speed high torque radial piston motor with advanced design in disc distribution flow, piston structure, high pressure rating, smooth running at very low speeds, available with different valves, brakes. It is widely applied in mining, crane, geologic drilling, construction machinery, etc.

Compact Poclain MS50 Hydraulic Pump Motor Parts , Hydraulic Pump Repair Kit

Compact Poclain MS50 Hydraulic Pump Motor Parts , Hydraulic Pump Repair Kit

Item No Desc Quan Remark Item No Desc Quan
1 Drive Shaft 1   11 Distributor 1
2 Front Cover 1   12 Rear Cover 1
3 Stator 1   13 Adjusting Shim 1
4 Rotor 1   14 Dynamic Frication 21
5 Piston 16   15 Static Frication 22
6 Roller 16   16 Brake Cylinder 1
7 Piston Ring 16   17 Brake Shaft 1
8 Bushing 16   18 Brake Plunger 1
9 Spring Pin 16   19 Cover Plate 1
10 Plastic Block 32

Product application

Now the products have been widely used in all kinds of engineering machinery,construction machinery, agricultural machinery, hoisting and conveying machinery, marine deck machinery and military special vehicle.

Poclain MS50 hydraulic piston motor using GANTRY CRANE EQUIPMENT

MOTOR MS02 ROTARY GROUP MS02 CAM RING MS02 WHEEL MOTOR REPAIR PARTSProduct Description

POCLAIN MS18 RADIAL PISTON MOTOR MS18 ROTARY GROUP MS18 CAM RING MS18 WHEEL MOTOR REPAIR PARTS
POCLAIN MSE18 RADIAL PISTON MOTOR MSE18 ROTARY GROUP MSE18 CAM RING MSE18 WHEEL MOTOR REPAIR PARTS
POCLAIN MS18 RADIAL PISTON MOTOR MS18 MOTOR REPAIR KITS MS18 SEAL KITS MS18 WHEEL MOTOR SEAL KITS
POCLAIN MKE18 RADIAL PISTON MOTOR MKE18 ROTARY GROUP MKE18 CAM RING MKE18 WHEEL MOTOR REPAIR PARTS
POCLAIN MS25 RADIAL PISTON MOTOR MS25 ROTARY GROUP MS25 CAM RING MS25 WHEEL MOTOR REPAIR PARTS
POCLAIN MS35 RADIAL PISTON MOTOR MS35 ROTARY GROUP MS35 CAM RING MS35 WHEEL MOTOR REPAIR PARTS
POCLAIN MS50 RADIAL PISTON MOTOR MS50 ROTARY GROUP MS50 CAM RING MS50 WHEEL MOTOR REPAIR PARTS
POCLAIN MS83 RADIAL PISTON MOTOR MS83 ROTARY GROUP MS83 CAM RING MS83 WHEEL MOTOR REPAIR PARTS
POCLAIN MS125 RADIAL PISTON MOTOR MS125 ROTARY GROUP MS125 CAM RING MS125 WHEEL MOTOR REPAIR PARTS
POCLAIN MSE05 RADIAL PISTON MOTOR MSE05 ROTARY GROUP MSE05 CAM RING MSE05 WHEEL MOTOR REPAIR PARTS
POCLAIN MSE08 RADIAL PISTON MOTOR MSE08 ROTARY GROUP MSE08 CAM RING MSE08 WHEEL MOTOR REPAIR PARTS
POCLAIN MSE18 RADIAL PISTON MOTOR MSE18 ROTARY GROUP MSE18 CAM RING MSE18 WHEEL MOTOR REPAIR PARTS

WE SPECIALIZING IN MANUFACTURING REPLACE REXROTH MCR AND POCLAIN MS SERIES RADIAL PISTON MOTOR,ROTARY GROUP AND CAM RING AS BELOW :
MCR03-160,MCR03-225,MCR03-255,MCR03-280,MCR03-325,MCR03-365,MCR03-400
MCR05-380,MCR05-470,MCR05-520,MCR05-565,MCR05-620,MCR05-680,MCR05-750,MCR05-820
MCR10-780.MCR10-940,MCR10-1120,MCR10-1250,MCR10-1340
MCR15-1130,MCR15-1250,MCR15-1500,MCR15-1780,MCR15-2150
MCR20-1750,MCR20-2100,MCR20-2500,MCR20-3000

POCLAIN MS SERIES RADIAL PISTON MOTOR,ROTARY GROUP AND CAM RING AS BELOW:
MS02 MS05 MS08 MS11 MS18 MS25 MS35 MS50 MS83 MS125 MSE05 MSE08 MSE18

Characteristics:
Modular Design:
Motor integral structure according to the modular design, with chip stacking, including mechanical output device, hydraulic device, mechanical brake device of three parts, which can be conveniently matched with various hose optimization.
High pressure, Excellent low-speed stability:
Using the automatic compensation oil distributor of plane type, with low sensitivity of pressure and temperature, automatic compensating the wear of the friction pair, so as to ensure high volumetric efficiency of motor for any time, the highest working pressure to 35MPS, symmetrical piston, high start efficiency, excellent low-speed performance, the lowest stable speed id less than or equal to 5r.p.m.
Bear axial and radial force:
Using an independent set of mechanical output device, reliable designing of output shaft and bearing, the power driving device with balance radial force and pure torque outputs, so the motor can bear large axial force and radial force, can be directly with gear output or installed on the vehicle driving wheel.
Multi-functions:
The motor can be added all kinds of hydraulic valves, mechanical brake, wheel output shaft and other components, motor can make a double displacement, multi-functions collocation can meet the needs of users in various fields.


This Series Hydraulic Motor is one kind of low speed high torque radial piston motor with advanced design in disc distribution flow, piston structure, high pressure rating, smooth running at very low speeds, available with different valves, brakes. It is widely applied in mining, crane, geologic drilling, construction machinery, etc.Radial Piston Motor MS02 MS05 MS08 MS11 MS18 MS25 MS35 MS50 MS83 MS125 MCR05 MCR03We also doing


Characteristics:
Modular Design:
Motor integral structure according to the modular design, with chip stacking, including mechanical output device, hydraulic device, mechanical brake device of three parts, which can be conveniently matched with various hose optimization.
High pressure, Excellent low-speed stability:
Using the automatic compensation oil distributor of plane type, with low sensitivity of pressure and temperature, automatic compensating the wear of the friction pair, so as to ensure high volumetric efficiency of motor for any time, the highest working pressure to 35MPS, symmetrical piston, high start efficiency, excellent low-speed performance, the lowest stable speed id less than or equal to 5r.p.m.
Bear axial and radial force:
Using an independent set of mechanical output device, reliable designing of output shaft and bearing, the power driving device with balance radial force and pure torque outputs, so the motor can bear large axial force and radial force, can be directly with gear output or installed on the vehicle driving wheel.
Multi-functions:
The motor can be added all kinds of hydraulic valves, mechanical brake, wheel output shaft and other components, motor can make a double displacement, multi-functions collocation can meet the needs of users in various fields.



Product Name Hydraulic Motor
Valving Type 1-Displacement valving, 2-Displacement valving(clockwise/counteclockwise)
Mounting Options With Mounting, Without Mounting
Certificate ISO9001
Time of warranty 1 Year after delivery
Delivery Time 3-5 days for stock products, 15-35 days for a production.
Application Geological Drilling Equipment, Vessel Deck Machinery, Harvester, Excavator, etc.
Description Radial Piston Motor MS02 MS05 MS08 MS11 MS18 MS25 MS35 MS50 MS83 MS125 MCR05 MCR03



Radial Piston Motor MS02 MS05 MS08 MS11 MS18 MS25 MS35 MS50 MS83 MS125 MCR05 MCR03

All of hydraulic products can be widely applied in hydraulic drive systems of mine construction machinery, cranes and transporting equipment, heavy-duty metallurgic machinery, petroleum and vessel deck machinery, machine tools, plastic machinery, geological drilling equipment, agricultural and forest machinery, working platform, lawn mowers, special vehicles, fishery winches, carpenter machinery and sawing machines, rubber machinery and other machinery in the hydraulic system. These products are especially applicable to screw drives of plastics injection machines, the drives of lifting winches and winding drums, driving tracks of rotating mechanisms and the drive of wheel traveling mechanisms.

Compact Poclain MS50 Hydraulic Pump Motor Parts , Hydraulic Pump Repair Kit

Compact Poclain MS50 Hydraulic Pump Motor Parts , Hydraulic Pump Repair Kit
